TomoElectrometer™ & TomoScanner™

Specifications

Jump to:


REF Number	91750 - TomoScanner™ Water Tank Scanner Controller Box and Water Tank
90016 - TomoElectrometer™ 8 Channel Electrometer
TomoElectrometer™ and TomoScanner™
Height	11.7 cm (4.6 in)
Width	30.5 cm (12.0 in)
Length	26.7 cm (10.5 in)
Water Tank
Inside Height	27.9 cm (11.0 in)
Inside Width	26.9 cm (10.6 in)
Inside Length	60.4 cm (23.8 in)
Outside Height	29.9 cm (11.8 in)
Outside Width	29.3 cm (11.5 in)
Outside Length	62.8 cm (24.7 in)
Wall Thickness	1.3 cm (0.51 in) nominal
TomoElectrometer™ General Dosimetry Channels	Rate range: 0.001 pA - 4.900 nA
Charge range	0.01 pC - 999,999 nC
Sample rate	100 Hz, t = 10 msec
Detector response time	500 msec (99.3% of max)
Digital filter of rate mode readings	< 2 sec
TomoElectrometer™ Fast Response Channels	Rate range (5-7): 0.001 pA - 4.900 nA
Charge range (5-7)	0.01 pC - 999,999 nC
Rate range (channel 8)	0.01 pA - 19.600 nA
Charge range (channel 8)	0.1 pC - 999,999 nC
Sample rate	100 Hz, t = 10 msec
Detector response time	165 msec (99.3% of max)
Scanning Arm Leadscrew Accuracy
Resolution	± .25 mm
Repeatability	± .25 mm
Power
TomoScanner™	36 VDC@1.39 A. Use only with supplied Globtek®, Inc. power supply model GTM21097-5048-12.0
TomoElectrometer™	9 VDC@1.7 A. Use only with supplied supplied Globtek®, Inc. power supply model GTM21089-1509-T3
Product Standards
TomoElectrometer™	CE0413, Externally certified IEC 60601-1, IEC 60601-1-2
Water Tank	CE0413, Externally certified IEC 61010-1
Software/Computer Requirements	Operating System: Windows 10 Professional, 64 bit recommended
Processor	Dual core, 1 GHZ; Quad core, 2 GHZ recommended
Memory	32-bit OS; 2GB, 4GB recommended; 64-bit OS; 4GB, 8 GB recommended
Runtime Environment	Visual C++ 2010 Runtime
Hard Drive	32 GB or greater, 3 GB free space
Screen Resolution	1024x768 or greater
Optical Drive	CD or DVD
Connectivity	IPv4 Lan, 100 Mbit/s or greater
