Specifications
Jump to:
| Key Specifications | |
|---|---|
| Phantom Dimensions | 250.7 x 320 x 210 |
| Material & Weight | 13.15kg, Virtual Water |
| 45 mm Sphere | 45mm diameter, 50.96cc volume, Blue Water |
| Kidney Target | 38.9cc Volume, Blue Water |
| Kidney Margin | 241.75cc volume, Adipose Fat |
| Triangle Target | 38.55cc volume, Blue Water |
| Triangle Margin | 104.29cc volume, Lung |
| Left Lung | 155.67cc volume, Lung |
| Insert Dimensions | |
| Film Rod Insert | 120.71mm L, 76.35mm D, Virtual Water |
| Film Rod Insert Target | 10.09cc volume, Acrylic |
| Film Rod Insert Pre-Cut Film | 104.3 x 65.2mm, Gafchromic Film |
| Spine Film Insert | 90 x 44.6 x 50.8mm, Virtual Water |
| Spine Film Insert Pre-Cut Film | 86.8 x 47.6mm, Gafchromic Film |
| Film Calibration Strip | 76.2 x 25.4mm. Gafchromic Film |
