Specifications
Jump to:
| Motion Control System | |
|---|---|
| Max Scanning Speed | 50 mm/s |
| Positioning Accuracy | ± 0.1 mm per axis |
| Positioning Repeatability | ± 0.1 mm per axis |
| PC Communication | Wireless or wired via RS-232 |
| Wireless Communication Protocol | Xbee RF |
| FCC ID | OUR-XBEE |
| IC ID | 4214A-XBEE |
| Control Method | Onboard controls, PC or via wireless pendant |
| Water Tank Dimensions (Length x Width x Height) | |
| Outer Dimensions | 683 mm x 693 mm x 542 mm |
| Scanning Dimensions | 480 mm x 480 mm x 410 mm |
| Wall Thickness | 12 mm |
| Other | Replaceable Fill/Drain Port |
| Lift and Reservoir Cart | |
| Vertical Range | 685 mm – 1185 mm (tank base to floor) |
| Water Pump | Electric fill, gravity drain |
| Water Capacity | 227.1 liters (60 gallons) |
| Fill Time | 6-8 min |
| Drain Time | 16-20 min |
| Precision Positioning Platform | |
| X / Y Fine Adjustment | ±12.5 mm |
| Fine rotational adjustment | ±1° |
| Discrete engagement | 10°, 45° and 90° intervals |
| DoseView 3D Electrometer | |
| Channels | 2 |
| Bias Voltage | 0, ±100-450 VDC (50 V increments) |
| Range | 2 pC – 999,999 nC |
| Resolution | 10 fC |
| Connector Type | Triaxial BNC or TNC |
| Operating Parameters | |
| Temperature | 15 to 35 °C |
| Relative Humidity | 20 to 80% non-condensing |
| Pressure | 650 to 770 mmHg (867 to 1027 hPa) |
| Storage/Shipping Parameters | |
| Temperature | -15 to 50 °C |
| Relative Humidity | 10 to 95% non-condensing |
| Pressure | 600 to 800 mmHg (800 to 1067 hPa) |
| DoseView 3D Power Requirements | |
| Lift and Reservoir Cart Motion Controller/Electrometer Power Supply | Protek Power, Model PMP150-14, Input: 100-240 VAC, 47-63 Hz, |
