IMSure 3D™ Software

IM Sure3 D 1

Modality

Task Group

Category

IM Sure3 D 1

Specifications

CPU x64-based processors 8C/16T, 1.4 GHz or faster
RAM 20 GB of RAM
Free Hard Disk Space 20 GB (installation)
Operating System Windows** Server 2012 R2 Standard or newer with IIS enabled (**Windows is a registered trademark of Microsoft Corporation.)
Software .NET 4.6.2, .NET 3.5 (Windows Server 2016+) IIS
Database Microsoft SQL Server 2012 Standard or newer
Monitor Medical grade with minimum native display resolution of 1024x768 and 32-bit color
Input Device Standard keyboard and wheeled mouse
Language English (US) or English (UK)
CPU x64-based processors 4C/8T, 1.4 GHz or faster
RAM 12 GB of RAM
Free Hard Disk Space 20 GB (Installation)
Operating System Windows** Server 2012 R2 Standard or newer with IIS enabled
Software .NET 4.6.2, .NET 3.5 (Windows Server 2016+) IIS
Database Medical grade with minimum native display resolution of 1024x768 and 32-bit color
Input Device Standard keyboard and wheeled mouse
Language English (US) or English (UK)
*Minimum specifications will allow users to run typical patient data using a “Fast” Minimum Uncertainty setting with a grid voxel size of 3mm x 3mm x 3mm.
IMSure 3D calculates dose for 3D conformal, IMRT, VMAT, SRS, SRS cones, SBRT (MLC-shaped treatment fields for photon plans), TomoTherapy, Halcyon, Electron, ZAP-X, and CyberKnife (cones, Iris, and MLC) plans. The following requirements are stipulated:
All beams of a treatment plan are assumed to be delivered by the same treatment machine.
All control points of a single beam are assumed to be delivered with the same beam energy.
DICOM plans that do not adhere to these stipulations are rejected.
